Weichai series 700kw generator set technical parameters
|
Generator set type |
Open type generator set |
|
Power Output |
700kW |
|
Voltage Output |
430V/230V |
|
Current Output |
720A |
|
Rated Frequency |
50Hz |
|
Rated Speed |
1500rpm |
|
Open frame unit weight |
7300(KG) |
|
Open type size |
3500*1500*1800(L×W×H mm) |
|
Acoustic Noise(LP7m) |
95dB(A) |
|
Engine Model |
8M33D890E200 |
|
Cooling method |
Closed cycle forced water cooling |
|
Intake method |
Supercharged intercooler |
|
Stator and rotor material |
Baosteel silicon steel sheet, copper insulated |
Related products
|
Engine Model |
Engine output power(kw) |
Engine output power(KVA) |
Rated current(A) |
Weight(kg) |
Overall dimension(mm) |
|
WP2.3D25E200 |
20 |
25 |
36 |
600 |
1600*680*1200 |
|
WP2.3D40E200 |
30 |
37.5 |
54 |
600 |
1600*680*1200 |
|
WP2.3D48E200 |
40 |
50 |
72 |
650 |
1650*700*1250 |
|
WP4.1D66E200 |
50 |
62.5 |
90 |
900 |
1800*750*1300 |
|
WP4.1D80E200 |
60 |
75 |
108 |
900 |
1800*750*1300 |
|
WP6D132E200 |
100 |
125 |
180 |
1300 |
2400*750*1400 |
|
WP6D152E200 |
120 |
150 |
216 |
1350 |
2400*750*1400 |
|
WP10D200E200 |
150 |
187.5 |
270 |
1550 |
2500*800*1500 |
|
WP10D264E200 |
200 |
250 |
360 |
2000 |
2800*1000*1650 |
|
WP13D385E200 |
300 |
375 |
540 |
2400 |
2900*1000*1650 |
|
WP13D405E200 |
320 |
400 |
576 |
2400 |
2900*1000*1650 |
|
WP13D440E310 |
350 |
437.5 |
630 |
2400 |
2900*1000*1650 |
|
WP13D490E310 |
400 |
500 |
720 |
3218 |
3500*1500*1800 |
|
6M33D633E200 |
500 |
625 |
900 |
5000 |
3700*1600*2200 |
|
6M33D725E310 |
600 |
750 |
1080 |
6200 |
3650*1500*1900 |
|
8M33D890E200 |
700 |
875 |
1260 |
7300 |
4000*1700*2100 |
|
12M26D968E200 |
800 |
1000 |
1440 |
7500 |
4200*2050*2300 |
|
12M33D1108E200 |
900 |
1125 |
1620 |
7500 |
4200*2050*2300 |
