KTA38 marine engine
Engine parameters
Type: V-type 12-cylinder four-stroke turbocharged intercooler
Displacement: 38.1 liters | Continuous power: 1200-1350HP (895-1001kW) @1800rpm
Peak torque: 5082N·m@1500rpm | Fuel consumption rate: 188g/kWh
The cylinder body is made of high-strength vermicular graphite cast iron (tensile strength 450MPa), the crankshaft is ion nitrided, and the design life exceeds 80,000 hours.
Dual-circuit cooling system (cylinder jacket water/intercooler water independent circulation), temperature difference control ±3℃.
Engine performance
Anti-corrosion optimization
The seawater pump is made of nickel-aluminum bronze, and the impeller is treated with a special coating, which increases the chloride ion corrosion resistance by 300%. The fully enclosed electrical system has a protection level of IP67 and is suitable for high salt spray environments.
Exhaust system
A dry exhaust manifold is used and equipped with a water cooling protection device. This design effectively reduces the fuel consumption of the engine, improves fuel utilization, and improves the overall performance of the engine.
Environmental compliance
Emission control, IMO Tier III certification: SCR system urea consumption 4.5L/h@75% load, NOx emissions <3.4g/kWh. Integrated soot sensor, DPF regeneration efficiency >98%.
Complete global service
When purchasing Cummins KTA38 marine engines, users will enjoy a full year of comprehensive warranty service provided by Cummins. At the same time, Cummins' global service network provides users with solid after-sales protection. No matter where the ship sails in the world, as long as there is a problem with the engine, users can get professional and efficient technical support and maintenance services in time. Cummins' professional service team has rich experience and superb technology, which can quickly diagnose and solve engine failures, ensure the normal operation of the ship, and minimize the losses and inconveniences caused to users by engine failures.
